Spezifikationen

Gehäuse

Aluminum

Display

4.1inch HD 720 x 1280 touch screen

Supported file formats

WAV, FLAC, WMA, MP3, OGG, APE, AAC, ALAC, AIFF, DFF, DSF

Max. PCM

8kHz ~ 768kHz (8/16/24/32bits per Sample)

Max. DSD

DSD64(1bit 2.8MHz), Stereo / DSD128(1bit 5.6MHz), Stereo / DSD256(1bit 11.2MHz), Stereo DSD512(1bit, 22.4MHz), Stereo

Output level

Unbalanced 3.3Vrms │ Balanced 6.3Vrms (Condition No Load)

DAC-Chip

AK4191EQ x2 & AK4499EX x4

Digitale Eingänge

USB Type-C input (for charging & PC & MAC)

Digital outputs

Unbalanced Out (3.5mm), Balanced Out 4.4mm (only 5-pole supported)

Network

802.11 a/b/g/n/ac (2.4/5GHz)

Bluetooth

V5.0 (A2DP, AVRCP, Qualcomm® aptX™ HD, LDAC, LHDC)

Abmessungen

2.72” (69.1mm)[W] x 4.70” (119.6mm)[H] x 0.74” (18.8mm)[D]

Gewicht

Aluminum about 8.36oz (237g)

Frequenzbereich

±0.020dB (Condition : 20Hz~20kHz) Unbalanced │ ±0.025dB (Condition : 20Hz~20kHz) Balanced ±0.032dB (Condition : 20Hz~70kHz) Unbalanced │ ±0.025dB (Condition : 20Hz~70kHz) Balanced

Signal-Rausch-Abstand

126dB @ 1kHz, Unbalanced │ 130dB @ 1kHz, Balanced

Kanaltrennung

-140dB @ 1kHz, Unbalanced │ -144dB @ 1kHz, Balanced

THD+N

0.0005% @ 1kHz, Unbalanced │ 0.0003% @ 1kHz, Balanced

Ausgangsimpedanz

Unbalanced Out 3.5mm (0.6ohm) │ Balanced Out 4.4mm(1.2ohm)

Storage / library

256GB [NAND]

Battery

4,200mAh 3.8V Li-Polymer

DAC-Architektur

Delta-sigma

Kopfhörerausgänge

3.5mm (1/8"), 4.4mm Pentaconn
